Máy đo công suất điện Kyoritsu 6305-00

6 đánh giá cho Máy đo công suất điện Kyoritsu 6305-00

1.

   Được xếp hạng 5 5 sao

   pv huy – 16/10/2018

   Power Meter
   KEW 6305
   KEW 6305
   CE
   • Comprehensive real-time monitoring, recording and analysis of single and 3-phase systems
   • Voltage, Current, Power Factor and Frequency measurements
   • Power analysis (Active, Apparent and Reactive power)
   • Energy analysis (Active, Apparent and Reactive power)
   • Active power accuracy: ±0.3%rdg±0.2%f.s.
   • Automatic wiring check function to prevent incorrect connections
   • Large memory capability (2GB) using built-in SD card interface
   • Real time & remote measurements using Android application
   • synchronous measurements between two units of KEW 6305
   • Wide selection of clamp sensors allow measurements from 0.1A to 3000A
   • The instrument automatically recognizes what kind of clamp sensor is connected to it
   • Windows software for data analysis and setting via USB port or Bluetooth
   TRUE RMSUSBBluetoothExternal
   KEW Smart 6305

   Get it on Google Play

   Free Android software “KEW smart 6305”
   is available on “Google Play Store”

   •Supporting Android ver. 3.0 – 7.0
   •WVGA (800 × 480) resolution or higher
   Please search “KEW Smart” in Google Play Store.
   Communication charge may be incurred separately to download application.
   Wiring connections 1P2W, 1P3W, 3P3W, 3P3W3A, 3P4W
   Measurements Voltage, Current, Frequency, Active power
   Parameters Apparent power, Reactive power, Active energy, Apparent energy,
   Reactive energy, Power factor (cos θ), Neutral current
   Voltage range[RMS] 150.0 / 300.0 / 600.0V
   Voltage accuracy ±0.2%rdg±0.2%f.s. (sine wave, 45 – 65Hz)
   Current range[RMS] 8128 ( 50A type ) : 1.000 / 5.000 / 10.00 / 25.00 / 50.00A / auto
   8127 ( 100A type ) : 2.000 / 10.00 / 20.00 / 50.00 / 100.0A / auto
   8126 ( 200A type ) : 4.000 / 20.00 / 40.00 / 100.0 / 200.0A / auto
   8125 ( 500A type ) : 10.00 / 50.00 / 100.0 / 250.0 / 500.0A / auto
   8124 ( 1000A type ) : 50.00 / 100.0 / 200.0 / 500.0 / 1000A / auto
   8130 ( 1000A type ) : 50.00 / 100.0 / 200.0 / 500.0 / 1000A / auto
   8129 ( 3000A type ) : 300.0 / 1000 / 3000A
   8133 ( 3000A type ) : 60.00 / 300.0 / 600.0 / 1500 / 3000A / auto
   Current accuracy ±0.2%rdg±0.2%f.s. + Accuracy of Clamp sensor (sine wave, 45 – 65Hz)
   (*) +1%f.s. at the lowest range
   Display range 5 – 130% of each range(Voltage)
   1 – 130% of each range(Current)
   Crest factor Voltage: up to 2.5, Current: up to 3.0 (with 90% fs or less)
   Allowable input ±0.3%rdg±0.2%f.s. + Accuracy of Clamp sensor
   (*) +1%f.s. when the lowest current ranges is selected.
   Effect of power factor Active power: ±1.0%rdg cos θ=±0.5 (PF=1)
   Frequency meter range 40.0 – 70.0Hz
   Frequency meter accuracy ±3dgt
   Accuracy precondition PF=1, Sine wave, 45 – 65Hz, 23ºC±5ºC
   Display update period 1 second
   Applicable standards IEC 61010-1 CAT III 600V
   Operating temperature & humidity range 0 – +50ºC, less than 85%RH (without condensation)
   Storage temperature & humidity range -20 – +60ºC, less than 85%RH (without condensation)
   Power supply (AC Line) AC100 – 240V±10% (50/60Hz)
   Power supply (DC battery) LR6 or Ni-MH (HR-15-51) ×6 (Battery charger not included),
   Battery life approx. 15h (LR6)
   Power consumption 10VA (max.)
   communication interface USB, Bluetooth
   PC card interface SD card (2GB)
   Dimensions 175(L)×120(W)×65(D) mm
   Weight Approx. 800g (including batteries)
   Included Accessories 7141B (Voltage test lead set: 4pcs)
   7148 (USB cable)
   7170 (Power cord)
   9125 (Carrying case)
   8326-02 (SD card 2GB)
   KEW WINDOWS (PC Software)
   Battery (LR6)×6
   Quick manual
   Optional Accessories 8124, 8125, 8126, 8127, 8128 (Clamp sensor)
   8129/8130/8133 (Flexible clamp sensor)
   8312 (Power supply adaptor)
   9132 (Magnetic carrying case)
   Set Model

   KEW 6305-01
   KEW 6305 × 1
   MODEL 8125 × 3
   7141B (Voltage test lead set: 4pcs) × 1
   7148 (USB cable) × 1
   7170 (Power cord) × 1
   8326-02 (SD card [2GB]) × 1
   9125 (Carrying case) × 1
   PC Software × 1
   Battery × 6
   Quick manual × 1

   KEW 6305-03
   KEW 6305 × 1
   KEW 8130 × 3
   7141B (Voltage test lead set: 4pcs) × 1
   7148 (USB cable) × 1
   7170 (Power cord) × 1
   8326-02 (SD card [2GB]) × 1
   9135 (Carrying case) × 1
   PC Software × 1
   Battery × 6
   Quick manual × 1
